FR24-MS301

FR24-MS301

FR24-MS301 Gesture Recognition Radar Module This radar module works in 24G frequency band, uses FMCW continuous wave frequency modulation, assists the smart toilet to automatically detect moving and standing human bodies, and can accurately measure distance. The reference design adopts a small horizontal angle of view to avoid triggering the circle when the human body passes by due to misjudgment. Users can quickly import into the smart product design, shorten the product development cycle.

Application areas and scenarios


Product parameter

Power frequency24  ~ 24.25GHz
With MCUOnboard MCU
Supply voltage3~5V
Power consumption＜40mA
Radiated power19dBm (typical value)
ModulationFMCW
Hardware size28*24mm
Ambient temperature-40℃~85℃
